iQ6-W6

iQ6‑W6

ISO 6,000 lumens, WUXGA, 3 X LCD laser phosphor projector

  • Brilliant image
  • Flexible installation
  • Barco service & support
This product is not available in your country/region
This product is currently only available in the following countries/regions: China Mainland 中国大陆

List price:

(excl. VAT, duties and freight)

Price not available

R9010561

iQ6-W6 - with lens (1.2 - 2.0)

Get product support

The iQ6 series expands Barco's projector product portfolio to offer users with high resolution and vivId colors. Thanks to a variety of correction functions, large lens shift, and 1.6X high magnification lens enable possibilities for convenient and rapid installation and wider applications, while providing valuable Barco services and support.

A new generation of laser light source, with high efficiency and low energy consumption, the laser modular design leads to improve the utilization of laser source and avoid the risk of sudden failures in important demonstrations. The four set of adjustable laser control extends the lifetime up to 20000 hours. Thanks to high heat resistance WUXGA inorganic LCD panel to offer constant vivid colors. With contrast optimization function on allows you access to high-resolution up to 3,000,000:1

Flexible installation

It supports correction functionalities as Keystone, 4-corner/6-coner, pillow/barrel distortion, multi-point, with 1.6X zoom lens functionality and the maximum lens shift range of 60% (upward) vertical direction and ± 29% in the horizontal direction, and Configures on 360 ° all-round installation function which ensure fast and convenient installation.

Barco Services & Support

With iQ6 series, you can enjoy Barco's mind of peace service. The laser light source not only guarantees good image quality, but also has lower maintenance costs than most lamp projectors on the market.

Specifications

Download spec sheet
General specifications
Projector type
3 X LCD laser phosphor projector
Resolution
1,920 x 1,200 (WUXGA) - 0.64" LCD
Brightness
6,000 ISO lumen*
Contrast ratio
3,000,000:1 (Contrast optimization ON)
Brightness uniformity
85% (Typical)
Aspect ratio
16:10
Lens type
iQ6 LENS (1.2- 2.0 : 1) Manual
Optical lens shift
iQ6 LENS (1.2- 2.0 : 1) Manual: H±29% V 0%, +60%
Manual zoom and focus
Manual lens shift
Color correction
No
CLO (constant light output)
No
Light source
Laser phosphor
Laser lifetime
20,000hrs
Orientation
360° rotation, no restrictions
3D
No
Image processing
Embedded warp
Keystone correction
Yes
Input
HDMI™ IN 1.4 x 2 /VGA IN x 1/VGA OUT x 1/ AUDIO IN x 1/AUDIO OUT x 1
Input resolutions
Up to 1,920 x 1,200 @ 60Hz/3,840 x 2,160 @ 30Hz
Control
IR, RS232, RJ45
Network connection
10/100 Ethernet, RJ45
Power requirements
100-240V / 50-60Hz
Power consumption
350W (full normal) /240瓦(Eco1) / 220瓦(Eco1)
Standby power
less than 0.5W(ECO)
Noise level (typical at 25°C/77°F)
37dB(full normal) / 29dB(Eco1) / 27dB(Eco1)
Operating temperature
0℃~40℃
Storage temperature
-10℃~50℃
Operating humidity
20%-85%
Storage humidity
10%-85%
Dimensions (WxLxH)
405mm x 373mm x 137mm
Weight
7.9KG
Standard accessories
Power cord, wireless remote control
Certifications
CCC/CECP/CELWEEE/China Rohs
Warranty
3 years or 20.000hrs runtime, whichever comes first; 5 years or 20.000hrs as an option
* Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2012 international standards
* ISO21118: The lower-limit values of the projector must maintain 80% of the values in specification sheets for the brightness
