iQ7‑W10

General specifications

Projector type

3 X LCD laser phosphor projector

Resolution

1920 x 1200

Brightness

10,000 ISO lumen*

Contrast ratio

 Extreme black: 100,000:1（Full on/Full Off, Dynamic ON)



Brightness uniformity

80%

Aspect ratio

16:10

Lens type

iQ7 LENS (1.46-2.95 : 1) STD Manual
iQ7 LENS (4.59-7.02 : 1) Manual
iQ7 LENS (0.79-1.11 : 1)
iQ7 LENS (1.30-3.02 : 1) STD
iQ7 LENS (2.99-5.93 : 1)
iQ7 LENS (0.32 : 1) UST
iQ7 LENS (0.6-0.75 : 1)



Optical lens shift

iQ7 LENS (1.46-2.95 : 1) STD Manual: H±30% V -10%, +50%
iQ7 LENS (4.59-7.02 : 1) Manual: H±30% V -10%, +50%
iQ7 LENS (0.79-1.11 : 1):H±20% V -10%, +50%
iQ7 LENS (1.30-3.02 : 1) STD:H±20% V -10%, +50%
iQ7 LENS (2.99-5.93 : 1):H±20% V -10%, +50%
iQ7 LENS (0.32 : 1) UST:
iQ7 LENS (0.6-0.75 : 1):
Manual or Motorized zoom and focus Motorized lens shift

Color correction

No

CLO (constant light output)

No

Light source

Laser phosphor

Laser lifetime

20,000hrs*





Orientation

360° rotation, no restrictions

3D

No

Image processing

Embedded warp



Keystone correction

Yes

Input

VGA x 1/ HDMI™ 1.4 x 2 / DVI-D x 1/ HD BaseT x 1

Input resolutions

Up to 1,920 x 1,200 @ 60Hz or 3,840 x 2,160 @ 30Hz



Control

IR, RS232, RJ45

Network connection

10/100 Ethernet, RJ45

Power requirements

100-240V / 50-60Hz

Power consumption

810W（220-240VAC, Typical）



Standby power

less than 0.5W

Noise level (typical at 25°C/77°F)

35.8 dB（Normal Mode）



Operating temperature

0℃~40℃

Storage temperature

-10℃~50℃

Operating humidity

20%-85%

Storage humidity

10%-85%

Dimensions (WxLxH)

600mm x 218mm x 503mm

Weight

24KG （excl. lens)



Standard accessories

Power cord, wireless remote control

Certifications

CCC/CECP/CEL

Warranty

*1:Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2012 international standards
*2:  ISO21118: The lower-limit values of the projector must maintain 80% of the values in specification sheets for the
brightness
