Next‑gen ClickShare Button
The iconic ClickShare Button experience, now with next-gen performance
- 4K content sharing for highly visual, impactful meeting experiences
- Better internet speed with Wi-Fi 6E for smooth collaboration
- Guest-friendly, one-click sharing via USB-C DisplayPort™; no software or driver downloads needed
- Secure and stable connection for uninterrupted meetings
- Compatible with all major operating systems
List price:
(excl. VAT, duties and freight)
Price not available
ClickShare Button - Gen 5
R9861700D01CUSClickShare Button - Gen 5 US version
The enhanced ClickShare Button 5th gen brings you the same simplicity you know — now powered with smarter technology and sharper performance. Just plug it into your laptop to instantly share ultra-high-definition content or join video calls wirelessly. With a focus on ease, speed, and visual impact, it’s designed to boost every meeting experience and enable crystal-clear presentations with zero friction.
Expected to be available end of 2025.
Specifications
Download spec sheetGeneral specifications
- Video outputs
- Up to 4K (3840x2160) 30fps
- Connectors
- USB Type-C 3.1 Gen1, supports USB-C DisplayPort™ Mode
- Authentication protocol
- WPA3-SAE in stand alone mode
- Wireless transmission protocol
- IEEE 802.11 a/b/g/n/ac/ax
- Reach
- Max. 30m (100ft) between ClickShare Button and ClickShare Base Unit
- Frequency band
- 2.4GHz, 5GHz and 6GHz
- Temperature range
- Operating: 0°C + 40°C (+32°F to +104°F) Storage: -20°C to +60°C (-4°F to + 140°F)
- Humidity
- Storage: 0 to 95% relative humidity, non-condensing Operation: 0 to 85% relative humidity, non-condensing
- Dimensions (HxWxD)
- 16 x 63 x 161.3 (mm)
- Power consumption
- Powered over USB 5V DC 600mA Typical 900mA Maximum
- Weight
- 88gr
