SAS‑050
Powerful server for use in Barco CTRL environment
- Security by design
- Redundancy option
- Compact form factor
List price:
(excl. VAT, duties and freight)
Price not available
SAS-050 Secure Appliance Server
R985005BSAS-050 Secure Appliance Server US
R985005BTWSAS-050 Secure Appliance Server TW
R985005DSAS-050 Secure Appliance Server IN
R985005FSAS-050 Secure Appliance Server EU
R985005GSAS-050 Secure Appliance Server UK
R985005ISAS-050 Secure Appliance Server CN
R985005IAUSAS-050 Secure Appliance Server AU
The SAS-050 is the service node for Barco CTRL, delivering the core functionality of the networked visualization system. This device manages all hardware, and orchestrates the collaboration and visualization of the information shared between the different displays and operator workstations in a Barco CTRL system.
Managing the security features of the Barco CTRL platform, the SAS-050 is a vital component of the system
Features and benefits
- Manages complete Barco CTRL system and its cybersecurity
- Handles collaboration and sharing of information
- Runs the Barco CTRL software
Specifications
Download spec sheetGeneral specifications
- Network
- 2 x 1Gb/s Ethernet - active failover
- Output
- OSD available
- USB
- 2x USB 3.0 (Type A)
\r\n2x USB 2.0 (Type A)
- Dimensions
- 28 x 180 x 190 mm without plastic cover 33 x 180 x 190 mm with plastic cover
- Power supply
- 19 DCV, 3.42A
- Power consumption
- 25W typical operation, max. 65W
- Weight
- 1.03 kg
- Temperature range
- 0° - 40°C | 32° - 104°F
- Humidity
- Max. 80% (noncondensing)
- Noise Level
- Max. 24dbA (measured at 1m/32.8ft distance at 25°C)
- Compliance
- CE, CB, UL, FCC Class B, BIS, KC, CU-EAC, CCC, DoC, RCM, TAA
Regulatory Model Name: P50_X
- MTBF
- 309,000 hours
- Order Information
- R985005B | Secure Appliance Server US
R985005D | Secure Appliance Server IN
R985005F | Secure Appliance Server EU
R985005G | Secure Appliance Server UK
R985005I | Secure Appliance Server CN
R985005AU | Secure Appliance Server AU
R985005BTW | Secure Appliance Server TW
R985005 | Secure Appliance Server No Power Cable
