4.10 Connecting an EC-30

Prerequisites

A computer with Event Master Toolset installed and a free ‘USB-A’ port is required to use the controller. For more information on how to install the Event Master Toolset, see “Event Master Toolset installation”.

EC-30 overview
Image 4–18
1
Power port
2
USB-B port
3
Strain relief tabs
4
Power adapter
How to connect
  1. Connect the power adapter (reference 4, Image 4–18) to the EC-30 power port (reference 1, Image 4–18).

  2. Plug the power adapter (reference 4, Image 4–18) into a wall socket.

    A light will go bounce back and forth among the ‘Destination’ buttons.

  3. Connect a ‘USB-B to USB-A’ cable from the ‘USB-B’ port of the EC-30 (reference 2, Image 4–18) to a free ‘USB-A’ port of the computer.

    The bouncing light will stop.

  4. Run the Event Master Toolset application on the connected computer.

  5. Is there a prompt to install the controller driver?

    • If yes, install the driver.
    • If no, no further actions required.
